Ultra-small on-site recording device
Model: RTX-SAKAI
High – end audio streamer is our latest solution combination of between audio transceiver and audio receiver. It is also can do recording on streaming. During operation, it is easily to switch the receiver from the current transceiver another.
Main Features:
- Live audio surveillance, remote control, receive file, listen live
- Store & Forward audio, recording and streaming
- Tiny digital transceivers
- 860-915 MHz frequency range
- Transmiiter control range up to 150 m LOS
- Less than 6 minutes for 1 hour of audio
- LCD screen receiver
- Included accessories: headset, battery and battery charger, integrated in hard suitcase
| Receiver Specifications |
|
|
Power |
3.7 VDC ( internal battery 4000 mAh) 5 V mini USB – external supply/charging |
|
LCD monitor |
Included |
|
Current line |
100-500 mAh, Continuous working time (with battery): 15h |
|
Download speed |
Min 0.5 Mbps |
|
Dimensions |
120x75x25 mm (not including battery) |
|
Weight |
500g (not including battery and memory stick) |
|
Storage |
8GB Micro SD card |
|
Headphone jack |
Included |
|
Transmit distance |
150 m LOS |
|
Decryption |
AES-128, ADPCM |
|
Working frequency |
8bit (8KHz) to 16bit ( 44Khz), 4 chs |
|
Recording |
Live transmission, turn on, turn off and change transmitter frequency |
|
Transmitter Specifications |
|
|
Power |
Between 3,6 – 5VDC/ 50mA |
|
Upload speed |
Min 0.5 Mbps |
|
Physical parameters |
Dimensions: 20x40x4mm (not including battery) Weight: 8g (not including battery and memory stick) |
|
Microphone inside |
Included |
|
Encryption |
AES-128, ADPCM |
|
Working frequency |
8bit (8KHz) to 16bit ( 44Khz) |
|
Control |
VOX, Schedule triggers, LED indication, Schedule recording |
|
Audio resolution |
16 bit |
|
Microphone |
Internal microphone |
|
Memory storage |
8GB Micro SD |
|
RF output gain |
Adjustable |
|
Transmission distance |
150m – Line of sight |
